2.5.25 PCH Core Voltage [Auto]
This item allows you to set the core voltage on the PCH (Platform Controller Hub). You can
use the <+> or <‑> keys to adjust the value. The values range from 0.73500V to 1.50000V
with a 0.00500V interval.
The system may need better cooling system for a more stable performance under high
voltage settings.
2.5.26 DRAM CTRL REF Voltage [Auto]
This item allows you to set the DRAM reference voltage on the control lines from the memory
bus. You can use the <+> or <‑> keys to adjust the value. The values range from 0.39500V to
0.63000V with a 0.00500V interval.
2.5.27 DRAM DATA REF Voltage on CHA/CHB [Auto]
This item allows you to set the DRAM reference voltage on the data lines on Channels A and
B. You can use the <+> or <‑> keys to adjust the value. The values range from 0.39500V to
0.63000V with a 0.00500V interval.
To set a value for the DRAM reference voltage, we recommend you to set a value close to
the standard value which is 0.500000x.
2.5.28 CPU Spread Spectrum [Auto]
This item allows you to enhance the BCLK overclocking capability or reduce the EMI
(electromagnetic disturbance) generated by the BCLK. Set this item to [Enabled] for EMI
reduction, or set this item to [Disabled] to enhance BCLK overclocking. Conguration options:
[Auto] [Disabled] [Enabled]
