CPU Fan Profile [Standard]
This item appears only when you enable the CPU Q‑Fan Control feature and allows you to
set the appropriate performance level of the CPU fan.
[Standard] Sets to [Standard] to make the CPU fan automatically adjust depending on
the CPU temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet CPU fan operation.
[Turbo] Sets to [Turbo] to achieve maximum CPU fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set CPU Fan Profile to [Manual].
CPU Upper Temperature [70]
Use the <+> and <‑> keys to adjust the upper limit of the CPU temperature. The values
range from 25ºC to 75ºC.
CPU Fan Max. Duty Cycle(%) [100]
Use the <+> and <‑> keys to adjust the maximum CPU fan duty cycle. The values
range from 20% to 100%. When the CPU temperature reaches the upper limit, the
CPU fan will operate at the maximum duty cycle.
CPU Middle Temperature [25]
Use the <+> or <‑> keys to set the value for CPU Middle Temperature. The range of
the values depends on the CPU installed.
CPU Fan Middle Duty Cycle(%) [20]
Use the <+> or <‑> keys to adjust the CPU fan middle duty cycle. The values range
from 20% to 100%. When the CPU temperature reaches the upper limit, the CPU fan
operates at the maximum duty cycle.
CPU Lower Temperature [20]
Use the <+> or <‑> keys to adjust the CPU fan’s lower temperature. The values range
from 20% to 75%.
CPU Fan Min. Duty Cycle(%) [20]
Use the <+> and <‑> keys to adjust the minimum CPU fan duty cycle. The values
range from 20% to 100%. When the CPU temperature is under the lower limit, the CPU
fan will operate at the minimum duty cycle.
2.7.5 Chassis Fan 1/2 Q-Fan Control [DC Mode]
These items allow you to set the chassis fans’ Q‑Fan control feature into DC Mode, PWM
Mode, or disable these Q‑Fan controls from your motherboard. Conguration options:
[Disabled] [DC Mode] [PWM Mode]
The following items appear only when you set the Chassis Fan 1/2 Q‑Fan Control to [PWM
Mode] or [DC Mode].
Chassis Fan 1/2 Q-Fan Source [CPU]
This item controls the assigned fan according to the selected temperature source.
Conguration options: [CPU] [MB]
