Asus M4A78 - Jumperfree Configuration

2-10 ASUS M4A78
2.4.1 JumperFree Conguration
CPU Overclocking [Auto]
Allows selection of CPU overclocking options to achieve desired CPU internal frequency.
Select any of the preset overclocking.
• Manual - Allows you to individually set the overclocking parameters.
• Auto - Loads the optimal settings for the system.
• Overclock Prole - Loads overclocking proles with optimal parameters for stability when
overclocking.
The following item appears only when the CPU Overclocking item is set to [Manual].
CPU/HT Reference Clock (MHz) [200]
Allows you to set the CPU/HT Reference Clock. The valid value is between 200 MHz
and 550 MHz.
The following item appears only when the CPU Overclocking item is set to [Overclock
Prole].
Overclock Options [Auto]
Allows you to set the overclock options. Conguration options: [Auto] [Overclock 2%]
[Overclock 5%] [Overclock 8%] [Overclock 10%]
PCIE Overclocking [Auto]
Allows you to select the PCIE Overclocking. Conguration options: [Auto] [Manual]
The following item appears only when the PCIE Overclocking item is set to [Manual].
PCIE Clock [100]
Allows you to set the PCIE clock. The valid value is between 100 and 150.
Processor Frequency Multiplier [Auto]
Allows you to select the processor frequency. Conguration options: [Auto] [x4.0 800 MHz]
[x5.0 1000 MHz] [x6.0 1200 MHz] [x7.0 1400 MHz] [x8.0 1600 MHz] [x9.0 1800 MHz]
CPU Over Voltage [Auto]
Allows you to select the processor voltage or set it to auto for safe mode.
Conguration options: [Auto] [+ 50mv] [+ 100mv] [+ 150mv]
VDDNB Over Voltage [Auto]
Allows you to select the NB voltage or set it to auto for safe mode.
Conguration options: [Auto] [+ 33mv] [+ 66mv] [+100mv]
HyperTransport Speed [Auto]
The Hyper Transport link will run at this speed if it is slower than or equal to the system clock
and the board is capable. Conguration options: [200 Mhz] [400 Mhz] [600 Mhz] [800 Mhz]
[1 Ghz] [Auto]
Hyper Transport Width [Auto]
The Hyper Transport link will run at this width. Conguration options: [Auto] [8 Bit] [16 Bit]
