Asus M4A88TD-M User Manual

ix
M4A88TD-M specications summary
(continued on the next page)
CPU AMD
®
Socket AM3 for AMD
®
Phenom™ II / Athlon™ II /
Sempron™ 100 series processors
Supports 45nm CPU
AMD
®
140W CPU support
AMD
®
Cool ‘n’ Quiet™ Technology
* Refer to www.asus.com for the AMD
®
CPU support list
Chipset AMD
®
880G / SB850
System Bus Up to 5200MT/s; HyperTransport™ 3.0 interface
Memory Dual-channel memory architecture
4 x DIMM, max. 16GB, DDR3 2000(O.C.)/1600(O.C.)/1333/1066MHz,
ECC, non-ECC, unbuffered memory*
* Due to CPU spec., AMD
®
100 and 200 series CPUs support up to
DDR3 1066MHz. With ASUS design, this motherboard can
support up to DDR3 1333MHz.
** Refer to www.asus.com for the latest Memory QVL (Qualied
Vendors List).
*** When you install a total memory of 4GB or more, Windows
®
32-bit operating system may only recognize less than 3GB. We
recommend a maximum of 3GB system memory if you are
using a Windows
®
32-bit operating system.
Graphics Integrated ATI Radeon™ HD 4250 GPU
Supports HDMI™ with max. resolution up to 1920x1080
Supports Dual-link DVI with max. resolution up to 2560x1600@60Hz
Supports D-Sub with max. resolution up to 2048x1536 @85Hz
Dual independent displays support with HDMI/DVI and D-Sub
Supports Microsoft
®
DirectX 10.1, OpenGL 2.0, and Shader Model 4.1
Hardware Decode Acceleration for H.264, VC-1, and MPEG-2
Maximum shared memory of 1GB
Supports Hybrid CrossFireX™
* Refer to www.amd.com for the discrete GPUs which support Hybrid
CrossFireX™.
Expansion slots 1 x PCIe 2.0 x16 slot
2 x PCIe 2.0 x1 slots
1 x PCI slot
Storage / RAID AMD
®
SB850 southbridge:
6 x Serial ATA 6Gb/s connectors support RAID 0, RAID 1, RAID 5,
and RAID 10 congurations
VIA
®
VT6415 PATA controller:
- 1 x Ultra DMA 133/100 connector for up to 2 PATA devices
Audio ALC892 8-channel High Denition Audio CODEC
- Supports 192khz/24bit BD Lossless Sound
- Supports Jack-detection, Multi-streaming, and Front Panel
Jack-Retasking (HD mode only)
- Optical S/PDIF Out port at back I/O
LAN Realtek
®
RTL8111E Gigabit LAN controller featuring AI NET 2

Asus M4A88TD-M Specifications

General

ECC	Yes
Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X4, AMD Phenom II X6
Number of COM connectors	1
Number of SATA III connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 880G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard southbridge	AMD SB850
Compatible operating systems	-
PCI Express x1 slots	2
PCI Express slots version	2.0
Graphics card	Radeon HD 4250
Maximum graphics card memory	1024 MB
RAID levels	0, 1, 5, 10
LAN controller	Realtek RTL8111E
Networking features	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	16 Mbit
Manageability features	WOL PME, WOR PME, WOR Ring, PXE

Weight and Dimensions

Width	244 mm
