Asus Maximus IV Extreme User Manual

1-2 Chapter 1: Product Introduction
1.3 Special features
1.3.1 Product highlights
Republic of Gamers
The Republic of Gamers consists only the best of the best. We offer the best
hardware engineering, the fastest performance, the most innovating ideas, and we
welcome the best gamers to join in. In the Republic of Gamers, mercy rules are
only for the weak, and bragging rights means everything. We believe in making
statements and we excel in competitions. If your character matches our trait, then
join the elite club, make your presence felt, in the Republic of Gamers.
Green ASUS
This motherboard and its packaging comply with the European Union’s Restriction
on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision
of creating environment-friendly and recyclable products/packaging to safeguard
consumers’ health while minimizing the impact on the environment.
LGA1155 socket for Intel
®
Second Generation Core™ i7 / Core™ i5 /
Core™ i3 Processors
This motherboard supports the Intel
®
second generation Core™ i7 / Core™
i5 / Core™ i3 processors in LGA1155 package with memory and PCI Express
controllers integrated to support 2-channel (4 DIMMs) DDR3 memory and 16
PCI Express 2.0 lanes. This provides great graphics performance. Intel
®
secondsecond
generation Core™ i7 / Core™ i5 / Core™ i3 processors are among the most processors are among the most
powerful and energy efcient CPUs in the world.
Intel
®
P67 Express Chipset
The Intel
®
P67 Express Chipset is the latest single-chipset design to support
the new 1155 socket Intel
®
Core™ i7 / Core™ i5 / Core™ i3 second generation
processors. It uses serial point-to-point links, which allows increased bandwidth
and stability, and provides an improved performance. It also provides two SATA 6.0
Gb/s and four SATA 3.0 Gb/s ports for faster data retrieval at double the bandwidth
of current bus systems.
Dual-Channel DDR3 2400(O.C.) / 2133(O.C.) / 1866(O.C.) / 1600 / 1333 / 1066
Support
The motherboard supports DDR3 memory that features data transfer rates of
2400(O.C.) / 2133(O.C.) / 1866(O.C.) / 1600 / 1333 / 1066 MHz to meet the
higher bandwidth requirements of the latest 3D graphics, multimedia, and Internet
applications. The dual-channel DDR3 architecture enlarges the bandwidth of your
system memory to boost system performance. Refer to page 2-5 for details.
* Due to CPU behavior, DDR3 2400/2200/2000/1800 MHz memory module will run at DDR3
2133/2133/1866/1600 MHz frequency as default.

Asus Maximus IV Extreme Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1600, 1866, 2133, 2600 MHz
Processor socket	LGA 1155 (Socket H2)
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Number of SATA connectors	8
Number of SATA II connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
Audio chip	Realtek ALC889
Component for	PC
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Compatible operating systems	Win
On-board graphics card	No
Parallel processing technology support	3-Way SLI
PCI Express slots version	2.0
RAID levels	0, 1, 5, 10
BIOS type	EFI
ACPI version	2.0a
BIOS memory size	32 Mbit
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Controller interface type	Marvell 9182 PCIe SATA6Gb/s
Controller 2nd interface type	JMicron 362
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Depth	269 mm
Width	305 mm
