ROG Maximus IV Extreme 1-7
Onboard Switches

With an easy press during overclock, this exclusive onboard switch allows gamer
to effortlessly ne-tune the performance without having to short the pins or moving
jumpers!
ASUS Q-Connector
Make connections quick and accurate
The Q-Connector allows you to connect or disconnect chassis front panel cables
in one easy step with one complete module. This unique adapter eliminates the
trouble of plugging in one cable at a time, making connection quick and accurate.
1.3.4 ASUS special features
ASUS TurboV EVO
The Ultimate O.C. Processor
The ultimate O.C. processor satises every level of overclockers—from die-hard
enthusiasts to beginners. Auto tuning intelligently pushes the system to the fastest
clock speeds while maintaining stability. Turbo Key boosts performance with just
one touch; while TurboV offers more options to advanced overclockers to achieve
world O.C. record. Moreover, upgrade your CPU at no additional cost with CPU
Level UP!
USB 3.0 Support
10X Faster Date Rates!
Experience ultra-fast data transfers at 4.8Gbps with USB 3.0—the latest
connectivity standard. Built to connect easily with next generation components and
peripherals, USB 3.0 transfers data 10X faster and is also backward compatible
with USB 2.0 components.
SATA 6Gb/s Support
Experience the Future of Storage!
Supporting next-generation Serial ATA (SATA) storage interface, this motherboard
delivers up to 6.0Gb/s data transfer rates. Additionally, get enhanced scalability,
faster data retrieval, double the bandwidth of current bus systems.

Asus Maximus IV Extreme Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1600, 1866, 2133, 2600 MHz
Processor socket	LGA 1155 (Socket H2)
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Number of SATA connectors	8
Number of SATA II connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
Audio chip	Realtek ALC889
Component for	PC
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
Compatible operating systems	Win
On-board graphics card	No
Parallel processing technology support	3-Way SLI
PCI Express slots version	2.0
RAID levels	0, 1, 5, 10
BIOS type	EFI
ACPI version	2.0a
BIOS memory size	32 Mbit
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Controller interface type	Marvell 9182 PCIe SATA6Gb/s
Controller 2nd interface type	JMicron 362
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Depth	269 mm
Width	305 mm
