1.1.10 ProbeIt
TheROGProbeItallowsyoutodetectyoursystemscurrentvoltageandOCsettings.Usea
multimetertomeasuretheProbeItpointsevenduringoverclocking.
SeetheillustrationbelowtolocatetherespectiveProbeItpoints.
Using ProbeIt
Youcanconnectthemultimetertothemotherboardasshownonthefollowinggure.
Theillustrationaboveisforreferenceonly,theactualmotherboardlayoutandmeasure
pointsmaydifferbymodel.
