1-24
Chapter 1: Product Introduction
Chapter 1
5. Front panel audio connector (10-1 pin AAFP)
Thisconnectorisforachassis-mountedfrontpanelaudioI/Omodulethatsupports
HDAudiostandard.ConnectoneendofthefrontpanelaudioI/Omodulecabletothis
connector.
Werecommendthatyouconnectahigh-denitionfrontpanelaudiomoduletothis
connectortoavailofthemotherboard’shigh-denitionaudiocapability.
6. LED connectors (5-pin RGB_LED_STRIP1; RGB_LED_STRIP2)
TheseLEDconnectorsareforconnectingLEDstripsonyourcoverandPCH.
