2.5.4 PCI Express x8 slot (x8 link)
TheonboardPCIE7provideonex8Gen3linktothePCH.Theseslotssupportvarious
server class high performance add-on cards.
2.5.5 PCI Express x16 slot (x16 link)
TheonboardPCIE6providesonex16Gen3linktoCPU.ThisslotsupportsVGAcardsand
various server class high performance add-on cards.
No.(Slot location) Short Description
1(slot7) PCIE7
1xPCI-Ex8(x8Gen3Link)
2(slot6) PCIE6 1xPCI-Ex16(x16Gen3link)
PCIeslot6sharesbandwidthwithPCIeslot7,whenPCIeslot7isoccupiedPCIeslot6will
run in x8 mode.
