Asus P11C-M/10G-2T - USB 2.0 Connector (10-1 Pin USB1112; 4-Pin Type-A USB7); USB 3.1 Gen 1 Connector (20-1 Pin USB3_34)

2-30
Chapter 2: Hardware Information
3. USB 2.0 connector
TheUSB2.0connectorallowsyoutoconnectaUSBmoduleforadditionalUSB
2.0ports.TheUSB2.0connectorprovidesdatatransferspeedsofupto480MB/s
connection speed.
DONOTconnecta1394cabletotheUSBconnectors.Doingsowilldamagethe
motherboard!
TheUSB2.0moduleispurchasedseparately.
4. USB 3.1 Gen 1 connector
TheUSB3.1Gen1connectorallowsyoutoconnectaUSB3.1Gen1modulefor
additionalUSB3.1Gen1ports.TheUSB3.1Gen1connectorprovidesdatatransfer
speedsofupto5Gb/s.
TheUSB3.1Gen1moduleispurchasedseparately.
ThepluggedUSB3.1Gen1devicemayrunonxHCIorEHCImodedependingonthe
operating system’s setting.
