ASUS P5N-E SLI 1-35
• For a fully congured system, we recommend that you use a power
supply unit (PSU) that complies with ATX 12 V Specication 2.0 (or
later version) and provides a minimum power of 400 W.
• Do not forget to connect the 4-pin ATX +12 V power plug;
otherwise, the system will not boot.
• Use of a PSU with a higher power output is recommended when
conguring a system with more power-consuming devices. The
system may become unstable or may not boot up if the power is
inadequate.
Power supply requirements
Loading
Components/Peripherals Heavy Normal Light
Intel
®
LGA775 CPU type Intel Pentium EE Intel Pentium D Intel Pentium 4
PCIe™ x16 graphics cards 6800 Ultra x2 6800GT x2 6600GT x2
DDR DIMMs 4 2 2
HDD 4 2 2
Optical drive (DVD/CD-RW) 2 2 1
PCIe™ x 1 card 1 0 0
PCI cards 2 2 1
USB devices 6 4 3
Required +12V current > 25A > 20A > 17A
Required wattage >= 500W >= 400W >= 350W
11. Digital audio connector (4-1 pin SPDIF_OUT)
This connector is for an additional Sony/Philips Digital Interface
(S/PDIF) port(s). Connect the S/PDIF Out module cable to this
connector, then install the module to a slot opening at the back of the
system chassis.
The S/PDIF module is purchased separately.
P5N-E SLI
R
P5N-E SLI Digital Audio Connector
+5V
SPDIFOUT
GND
SPDIF_OUT
