Asus P5W User Manual

6-2 Chapter 6: ATI
®
MVP technology support
Slave graphics card Master graphics card
2. Insert the CrossFire™ Edition (Master) graphics card into the PCI Express
x16 orange slot. Make sure that the card is properly seated on the slot.
6.2 Installing CrossFire™ graphics cards
Before ins talling a CrossFire™ system, refer to the user guide that came with
the ATI
®
CrossFire™ Edition graphics card.
To install the graphics cards:
1. Prepare one CrossFire™ Edition (Master) graphics card and one
CrossFire™-ready (Slave) graphics card.

Asus P5W Specifications

General

Form Factor	ATX
Socket	LGA 775
Memory Type	DDR2
Maximum Memory	8 GB
PCIe x16 Slots	2
PCIe x1 Slots	1
PCI Slots	3
LAN	Gigabit Ethernet
Chipset	Intel 975X
Memory Slots	4
SATA Ports	6
IDE Ports	1
USB Ports	8
Audio	8-channel HD Audio
