ASUS P7P55D-E 1-1
1.1 Welcome!
Thank you for buying an ASUS
®
P7P55D-E motherboard!
The motherboard delivers a host of new features and latest technologies, making it another
standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the items in
your package with the list below.
1.2 Package contents
Check your motherboard package for the following items.
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for your reference only. Actual product specications
may vary with different models.
Chapter 1: Product introduction
Chapter 1
User Manual
ASUS P7P55D-E motherboard User guide Support DVD
2 x Serial ATA 3.0Gb/s cables
2 x Serial ATA 6.0Gb/s cable
with 6.0Gb/s label
1 x Ultra DMA 133/
100/66 cable
1 x ASUS Q-Shield 1 x 2-in-1 ASUS Q-Connector kit

Asus P7P55D-E - Premium Motherboard - ATX Specifications

General

Form Factor	ATX
Chipset	Intel P55
CPU Socket	LGA 1156
Maximum Memory	16GB
Memory Type	DDR3
Memory Standard	DDR3 2200(O.C.)/1600/1333/1066
PCI Express x16	2
PCI Express x1	2
SATA 3Gb/s	6
SATA 6Gb/s	2
Audio Chipset	VIA VT2020
LAN Chipset	Realtek 8112L
Max. LAN Speed	10/100/1000Mbps
USB 2.0	12
USB 3.0	2
Memory Slots	4 x DIMM
Audio Channels	8 Channels
eSATA	1 x eSATA 3Gb/s
Dimensions	30.5 cm x 24.4 cm
Power Connector	24-pin ATX
RAID Support	0, 1, 5, 10
