ASUS P8B-E/4L 6-3
6.1 RAID driver installation
After creating the RAID sets for your server system, you are now ready to install
an operating system to the independent hard disk drive or bootable array. This part
provides the instructions on how to install the RAID controller drivers during OS
installation.
6.1.1 Creating a RAID driver disk
The system does not include a oppy drive. You have to use a USB oppy drive
when creating a SATA RAID driver disk.
If you have created RAID sets with the LSI Software RAID conguration utility,
the boot priority of the SATA optical disk drive has to be manually adjusted.
Otherwise, the system will not boot from the connected SATA ODD.
A oppy disk with the RAID driver is required when installing Windows
®
or
Red Hat
®
Enterprise operating system on a hard disk drive that is included in
a RAID set. You can create a RAID driver disk in DOS (using the Makedisk
application in the support DVD).
To create a RAID driver disk in DOS environment
1. Place the motherboard support DVD in the optical drive.
2. Restart the computer, and then enter the BIOS Setup.
3. Select the optical drive as the rst boot priority to boot from the support DVD.
Save your changes, and then exit the BIOS Setup.
4. Restart the computer. The Makedisk menu appears.
Create Driver Diskette Menu
C20x INTEL RAID Driver
C20x LSI RAID Driver
LSI 2008 SAS2 Driver
Write DMI
FreeDOS command prompt
5. Use the arrow keys to select the type of RAID driver disk you want to create
and press <Enter> to enter the sub-menu.
C20x INTEL RAID Driver
C20x INTEL RAID Driver
Windows 32 bit(also support AHCI)
Windows 64 bit(also support AHCI)
Back
Exit

Asus P8B-E/4L Specifications

General

Microphone in	No
Serial ports quantity	0
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 2.0 connectors	3
Chassis intrusion connector	Yes
PCI Express slots version	2.0
Memory channels	Dual-channel
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
PCI Express slots quantity	6
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
LAN controller	Intel® 82574L
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2050
On-board graphics card memory	16 MB
Parallel processing technology support	Not supported
Certification	FCC, CFR47 15, B, CE, EN55022, EN55024, C
Component for	Server
Motherboard chipset	Intel® C204
Motherboard form factor	ATX
Cables included	SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1155 (Socket H2)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Processor number of cores supported	2, 4

Weight and Dimensions

Depth	304.8 mm
Width	243.8 mm
