ASUS P8B-E/4L 6-7
4. Insert the RAID driver disk you created earlier to the USB oppy disk drive,
then press <Enter>.
5. Select the RAID controller driver you need from the list, then press <Enter>.
6. The Windows
®
Setup loads the RAID controller drivers from the RAID driver
disk. When prompted, press <Enter> to continue installation.
7. Setup then proceeds with the OS installation. Follow screen instructions to
continue.
To an existing Windows
®
Server OS
To install the RAID controller driver on an existing Windows
®
Server OS
1. Restart the computer, and then log in with
Administrator
privileges.
2. Windows
®
automatically detects the RAID controller and displays a
New
Hardware Found
window. Click
Cancel
.
3. Right-click the
My Computer
icon on the Windows
®
desktop, and then select
Properties
from the menu.
4. Click the
Hardware
tab, and then click the
Device Manager
button to display
the list of devices installed in the system.
5. Right-click the
RAID controller
item, then select
Properties
.
6. Click the
Driver
tab, and then click the
Update Driver
button.
7. The
Upgrade Device Driver Wizard
window appears. Click
Next
.
8. Insert the RAID driver disk you created earlier to the USB oppy disk drive.
9. Select the option
Install the software automatically (Recommended)
, and
then click
Next
.
10. The wizard searches the RAID controller drivers. When found, click
Next
to
install the drivers.
11. Click
Finish
after the driver installation is done.
ENTER=Continue ESC=Cancel F3=Exit
Windows Setup
Please insert the disk labeled
Manufacturer-supplied hardware support disk
into Drive A:
* Press ENTER when ready.

Asus P8B-E/4L Specifications

General

Microphone in	No
Serial ports quantity	0
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 2.0 connectors	3
Chassis intrusion connector	Yes
PCI Express slots version	2.0
Memory channels	Dual-channel
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
PCI Express slots quantity	6
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
LAN controller	Intel® 82574L
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2050
On-board graphics card memory	16 MB
Parallel processing technology support	Not supported
Certification	FCC, CFR47 15, B, CE, EN55022, EN55024, C
Component for	Server
Motherboard chipset	Intel® C204
Motherboard form factor	ATX
Cables included	SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1155 (Socket H2)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Processor number of cores supported	2, 4

Weight and Dimensions

Depth	304.8 mm
Width	243.8 mm
