Chapter 2: BIOS information 2-17
CPU C3 Report [Enabled]
Allows you to disable or enable the CPU C3 report to the operating system. Conguration
options: [Disabled] [Enabled]
CPU C6 Report [Enabled]
Allows you to disable or enable the CPU C6 report to the operating system. Conguration
options: [Enabled] [Disabled]
2.5.2 System Agent Conguration
Initiate Graphic Adapter [PEG/iGPU]
Allows you to decide which graphics controller to use as the primary boot device.
Conguration options: [iGPU] [PCI/iGPU]
iGPU Memory [64M]
Allows you to set the iGPU memory size. Conguration options: [32M] [64M] [96M] [128M] ~
[416M] [448M] [480M] [512M]
Render Standby [Enabled]
Allows you to enable or disable Render Standby by internal graphics devices. Conguration
options: [Disabled] [Enabled]
iGPU Multi-Monitor [Disabled]
Allows you to enable or disable the internal graphics device’s multi-monitor support for
add-on VGA devices. And the memory size for internal graphics device will keep 64MB.
Conguration options: [Disabled] [Enabled]
2.5.3 PCH Conguration
High Precision Timer [Enabled]
Allows you to enable or disable the High Precision Event Timer.
Conguration options: [Enabled] [Disabled]
2.5.4 SATA Conguration
While entering Setup, the BIOS automatically detects the presence of SATA devices. The
SATA Port items show Not Present if no SATA device is installed to the corresponding SATA
port.
SATA Mode [IDE Mode]
Allows you to set the SATA conguration.
[Disabled] Disables the SATA function.
[IDE Mode] Set to [IDE Mode] when you want to use the Serial ATA hard disk drives as
Parallel ATA physical storage devices.
[AHCI Mode] Set to [AHCI Mode] when you want the SATA hard disk drives to use the
AHCI (Advanced Host Controller Interface). The AHCI allows the onboard
storage driver to enable advanced Serial ATA features that increases
storage performance on random workloads by allowing the drive to
internally optimize the order of commands.
Due to the Intel
®
H61 chipset limitation, AHCI Mode only works on Windows
®
7/Vista.
Please use IDE Mode on Windows
®
XP.

Asus P8H61-M LX3 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Max Memory	16 GB
PCIe x16 Slots	1
SATA Ports	4 x SATA 3Gb/s
Audio Chipset	Realtek ALC887
Ethernet	10/100/1000 Mbps
USB Ports	8 x USB 2.0
Audio	Realtek ALC887
LAN	Realtek 8111E
Video Outputs	D-Sub
