2-24 ASUS P8H61-M LX3 Series
2.7.4 Option ROM Messages [Force BIOS]
[Force BIOS] The third-party ROM messages will be forced to display during the boot
sequence.
[Keep Current] The third-party ROM messages will be displayed only if the third-party
manufacturer had set the add-on device to do so.
2.7.5 Setup Mode [EZ Mode]
[Advanced Mode] Sets Advanced Mode as the default screen for entering the BIOS setup
program.
[EZ Mode] Sets EZ Mode as the default screen for entering the BIOS setup program.
2.7.6 Boot Option Priorities
These items specify the boot device priority sequence from the available devices. The
number of device items that appears on the screen depends on the number of devices
installed in the system.
To select the boot device during system startup, press <F8> when ASUS Logo appears.
To access Windows OS in Safe Mode, press <F8> after POST.
2.7.7 Boot Override
These items displays the available devices. The number of device items that appears on
the screen depends on the number of devices installed in the system. Click an item to start
booting from the selected device.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus P8H61-M LX3 and is the answer not in the manual?

Asus P8H61-M LX3 Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetIntel H61
CPU SocketLGA 1155
Memory Slots2
Memory TypeDDR3
Max Memory16 GB
PCIe x16 Slots1
SATA Ports4 x SATA 3Gb/s
Audio ChipsetRealtek ALC887
Ethernet10/100/1000 Mbps
USB Ports8 x USB 2.0
AudioRealtek ALC887
LANRealtek 8111E
Video OutputsD-Sub
