1-23 Chapter 1: Product introduction
In single VGA card mode, use the PCIe 2.0 x16_1 slot (blue) for a PCI Express x16
graphics card to get better performance.
We recommend that you provide sufcient power when running CrossFireX™ mode.
See page 1-30 for details.
Connect a chassis fan to the motherboard connector labeled CHA_FAN1 or CHA_FAN2
when using multiple graphics cards for better thermal environment.
The PCIe x1 slots share the bandwidth with the PCIe x16_2 slot. Due to the
CrossFireX™ limitation, DO NOT use the PCIe x1 slots when you install two
CrossFireX™ graphics cards on both the PCIe x16 slots to set up a CrossFireX™
conguration. To disable the PCIe x1 slot, refer to the Onboard Devices Conguration
section in the BIOS for details.
VGA conguration
PCI Express operating mode
PCIe x16_1 PCIe x16_2
Single VGA/PCIe card x16 (Recommended for single VGA card) x2
Dual VGA/PCIe card x16 x4
