2-16 ASUS P8P67 LX
Primary Plane Current Limit [Auto]
Use the <+> and <-> keys to adjust the value.
2.4.9 Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
CPU Offset Voltage [Auto]
Allows you to set the Offset voltage. The values range from 0.005V to 0.635V with a 0.005V
interval.
Refer to the CPU documentation before setting the CPU voltage. Setting a high voltage
may damage the CPU permanently, and setting a low voltage may make the system
unstable.
2.4.10 DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.185V to 2.135V with a 0.005V
interval.
According to Intel CPU specication, DIMMs with voltage requirement over 1.65V may
damage the CPU permanently. We recommend you install the DIMMs with the voltage
requirement below 1.65V.
2.4.11 VCCIO Voltage [Auto]
Allows you to set the VCCIO voltage. The values range from 0.7350V to 1.6850V with a
0.005V interval.
2.4.12 PCH Voltage [Auto]
Allows you to set the Platform Controller Hub voltage. The values range from 0.7350V to
1.6850V with a 0.005V.
• The values of the CPU Offset Voltage, DRAM Voltage, VCCIO Voltage, and PCH
Voltage items are labeled in different color, indicating the risk levels of high voltage
settings.
• The system may need better cooling system to work stably under high voltage settings.
2.4.13 Load-Line Calibration [Auto]
Load-line is dened by Intel VRM specication and affects CPU voltage. The CPU working
voltage will decrease proportionally to CPU loading. Higher load-line calibration would get
higher voltage and better overclocking performance, but increase the CPU and VRM thermal.
This item allows you to set this function for better system performance. Conguration options:
[Auto] [Disabled] [Enabled]
The actual performance boost may vary depending on your CPU specication.
2.4.14 CPU Spread Spectrum [Auto]
[Auto] Automatic conguration.
[Disabled] Enhances the BCLK overclocking ability.
[Enabled] Sets to [Enabled] for EMI control.

Asus P8P67 LX Specifications

General

Chipset	Intel P67
Socket	LGA 1155
Memory Type	DDR3
Maximum Memory	32GB
Storage Interfaces	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Form Factor	ATX
Memory Standard	DDR3 2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4
Expansion Slots	2 x PCIe 2.0 x1, 3 x PCI
LAN	Realtek 8111E Gigabit LAN
Audio	8-Channel High Definition Audio
USB Ports	12 (6 x USB 2.0, 6 x USB 3.0)
