Asus PA329C Series - Chapter 2: Setup and Installation; Assembling and Detaching the Monitor Base

2-1ASUS PA329C Series LCD Monitor
2.1 Attaching the arm/base
To assemble the monitor base:
1. Have the front of the monitor face down on a table. (Figure 1)
2. Attach the base into the arm, making sure the tab on the arm ts into the
groove on the base (Figure 2).
2
1
(Figure 1)
(Figure 2)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
2.2 Detaching the arm/base
(for VESA wall mount)
The detachable arm/base of this monitor is specially designed for VESA wall
mount.
To detach the arm/base:
1. Have the front of the monitor face down on a table.
2. Press the release button, and then detach the arm/base from the monitor (Figure
2).
2
1
(Figure 1)
(Figure 2)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
