1-4
Chapter 1: System introduction
1. Voltage selector. This switch allows you to adjust the system input voltage according
to the voltage supply in your area. See the section Voltage selector on page 1-8
before adjusting this switch.
2. Power connector. This connector is for the power cable and plug.
3. PS/2 keyboard/mouse combo port. This port is for a PS/2 keyboard or PS/2 mouse.
4. USB 2.0 ports 1 ~ 6. These 4-pin Universal Serial Bus (USB) ports are available for
connecting USB 2.0 devices.
5. DVI-D port. This port is for any DVI-D compatible device. DVI-D can’t be converted to
output RGB Signal to CRT and isn’t compatible with DVI-I.
6. Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other
VGA-compatible devices.
7. Microphone port (pink). This port connects a microphone.
8. Line Out port (lime). This port connects a headphone or a speaker. In 4-channel, 6-
channel, and 8-channel congurations, the function of this port becomes Front Speaker
Out.
9. Line In port (light blue). This port connects the tape, CD, DVD player, or other audio
sources.
Audio 2, 4, 6, or 8-channel conguration
10. Expansion slot covers. Remove these covers when installing expansion cards.
11. LAN (RJ-45) port. This port allows gigabit connection to a Local Area Network (LAN)
through a network hub. Refer to the table below for the LAN port LED indications.
Refer to the audio conguration table below for the function of the audio ports in 2, 4, 6, or
8-channel conguration.
Port Headset 2-channel 4-channel 6-channel 8-channel
Light Blue (Rear panel) Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out
Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center
Lime (Front panel) – – – Side Speaker Out
To congure an 8-channel audio output:
Use a chassis with HD audio module in the front panel to support 8-channel audio output.
