4-20 Chapter 4: BIOS setup
4.5 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
4.5.1 CPU Temperature / MB Temperature [xxx�C/xxx�F][xxx�C/xxx�F]
The onboard hardware monitor automatically detects and displays the CPU and motherboard
temperatures. Select Ignore if you do not wish to display the detected temperatures.
4.5.2 CPU / Chassis Fan Speed [xxxx RPM] or [Ignore] /
[N/A]
The onboard hardware monitor automatically detects and displays the CPU, chassis,
and power fan speeds in rotations per minute (RPM). If the fan is not connected to the fan speeds in rotations per minute (RPM). If the fan is not connected to the
motherboard, the eld shows N/A. Select Ignore if you do not wish to display the detected
speed.
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Main
Advanced Monitor Boot Tool
CPU Temperature
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
EFI BIOS Utility - Advanced Mode
Exit
CPU Temperature +52ºC / +125ºF+52ºC / +125ºF
MB Temperature +38ºC / +100ºF
CPU Fan Speed 2129 RPM
Chassis Fan N/A
CPU Q-Fan Control Enabled
Chassis Q-Fan Control Enabled
CPU Voltage +1.168 V
3.3V Voltage +3.296 V
5V Voltage +5.080 V
12V Voltage +12.096 V
Anti Surge Support Enabled
