Chapter 1: Product Introduction
1.3 Assembling the monitor
To assemble the monitor:
1. Placethedisplayonaclothonthetable,Useascrewdrivertotighten
theassemblyscrews,andsecurethearmtothedisplaytightly.Then
attachthehingecovertomonitorbody,attachthebasetothearmand
xwiththescrewtojointhemtightly.Youcaneasilytightenthescrew
byngers.
2. Adjustthemonitortotheanglethatismostcomfortableforyou.
2
1
3
4
5
1.4 Outline dimension
Unit: mm [inch]
