Asus VY279HF Series - VESA Wall Mount Preparation; Detaching the Monitor Stand

2-1
ASUS LCD Monitor VY279HF Series
2.1 Detaching the arm/stand (for VESA wall
mount)
ThedetachablestandofthismonitorisspeciallydesignedforVESAwall
mount.
To detach the arm/stand
1. Disconnectpowerandsignalcables.Carefullyput the front of the
monitor face down on a clean table.
2. Removethehingecoverfrommonitorbodybyusingyourngers.
3. Useascrewdrivertoremovethescrewsonthearm,andthendetach
the arm/stand from the monitor.
• Werecommendthatyoucoverthetablesurfacewithsoftclothtoprevent
damage to the monitor.
• Hold the stand of the monitor while removing the screws.
2
1
3
4
5
• TheVESAwallmountkit(100x100mm)ispurchasedseparately.
• UseonlytheULListedWallMountBracketwithminimumweight/load12kg
(Screwsize:M4x10mm).
