Asus X415DA - Wlan Module

Disassembly Procedure
19
WLAN Module
The illustrations below show how to remove the WLAN Module.
1. Remove 1 screw and take out the WLAN.
Screw tightening torque: 2.0KG±0.2kgf
SCREW M2*3L D4.5 (K) W-NI NY
Notice:
Please choose the J2 connector to connect with antenna if it is only single antenna for WLAN Card.
Parts:
⚫ Total screw * 1
⚫ 802.11AC+BT5.0(1*1)M.2_WW_1ANT//IN/9461.NGWG.NV958855JFP1/BLK *1
⚫ (Actual part name depends on different SKU.)
