Disassembly Procedure
28
Keyboard Module
The illustrations below show how to remove the Keyboard Module.
Follow the direction of the arrows to rotate the hinges, take out the Keyboard. .
Parts:
Total screw * 0
Keyboard Module*1
(Actual part name depends on different SKU.)
