ASUS Xonar DSX
5.3.3 Connecting 4/4.1 Channel Speakers
No Item Description
1 Front Out Connects to the Front input port of the 4/4.1 speakers with the mini-
jack cable.
2 Side Surround Out Connects to the Surround input port of the 4/4.1 speakers with the
mini-jack cable.
1
2
1
2
4 Speakers
4.1 Speakers
