Asus Xonar DSX User Manual

iii
Contents
Notices ......................................................................................................... iv
Safety information ....................................................................................... v
Trademarks ................................................................................................... v
License ......................................................................................................... v
1. Introduction .....................................................................................
1
1.1 Package contents .................................................................
1
1.2 System requirements ...........................................................
1
1.3
Specications summary ....................................................... 2
2. Xonar DSX card layout ...................................................................
4
3. Installing the hardware ...................................................................
6
3.1 Installing the audio card .......................................................
6
3.2 Connecting to a TV tuner card .............................................
7
4. Installing software ...........................................................................
8
Installing the card driver .................................................................... 8
5. Connecting speakers and peripherals ..........................................
9
5.1 Connecting digital speaker systems (Home Theater) ..........
9
5.2 Connecting stereo headphones .........................................
10
5.3 Connecting Analog Speaker Systems ................................
12
5.4 Connecting microphone .....................................................
17
5.5 Connecting Line-In audio sources ......................................
18
6. Xonar Audio Center
....................................................................... 19
6.1 Xonar Audio Center GUI ....................................................
19
6.2 Main Setting .......................................................................
21
6.3 Mixer/Volume .....................................................................
27
6.4 Effects ................................................................................
30
6.5 Karaoke ..............................................................................
32
6.6 FlexBass ............................................................................
34
6.7 Smart Volume Normalization ..............................................
35
6.8 DS3D GX and DSP Modes ................................................
37
6.9 VocalFX ..............................................................................
39
7. Troubleshooting and FAQs ..........................................................
42
[Troubleshooting] ............................................................................ 42
[FAQ] ...........................................................................................
44

Asus Xonar DSX Specifications

General

Internal	Yes
Audio quality	24 bit
Frequency range	10 - 48000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Line-in Signal-to-Noise Ratio (SNR)	100 dB
Line-out Signal-to-Noise Ratio (SNR)	107 dB
Line-in Total Harmonic Distortion (THD)	0.0017 %
Headphone outputs	4
Chipset	Asus AV66
Cables included	S/PDIF
Dolby technologies	Dolby Digital DTS, Dolby Digital DTS Connect

Weight and Dimensions

Depth	64.4 mm
Width	167.64 mm
