ASUS Xonar DSX
No Item Description
1 Support link Clicking this button will lead you to the ASUS ofcial website.
2 Display Area This display area shows the 10-band signal meter, volume level, and
the status of the Dolby/DTS technologies, EQ, and DSP modes. Note:
this area just displays information, but is not used to alter settings.
3 Setting Menu Panel This panel gives access to setting tabs, including Main Settings,
Mixer/volume, Effects, Karaoke, FlexBass, and VocalFX.
4 Information icon Clicking this icon will pop up driver’s Information window.
5 Menu Open/Close Clicking this button will move the display area and reveal the
conguration area below. Clicking it again will move the display area
back down.
6 Master Volume This rotary knob controls the master playback volume. Drag the small
circle inside it to change the volume level.
7 Mute Button Click this button to mute audio playback; it will display a red light
when playback is muted.
8 SVN Button Click this button to enable the “Smart Volume Normalization” feature
for constant volume from all playback sources. It will display a blue
light when enabled.
9 DSP Mode These 2 buttons give access to quick gaming surround sound effect
(GX2.5) and effect-free (Hi-Fi) modes.
