ASUS Xonar DSX
6.3.2 Recording/Monitoring Volume
No Item Description
1 Recording Volume Tab Click this button to show the recording volume page.
2 Recording volume
slider
Drag this slider down to decrease the recording volume; drag up to
increase the recording volume. The tool-tip reveals the percentage
number from 1 to 100 in terms of the full scale level.
3 Recording Selector
button
Click this button to select the path/source you are going to record.
Note that the recording function on Windows is a one-path selector.
So, you can select only one default recording source at a time. You
may have to restart the recorder program if you switch to a different
source. (Note: On Vista, some application programs may allow
you to select the recording device/path in the recording programs
themselves.)
4 Microphone-In
Advanced Setting
Click this button to open the advanced settings for the
Microphone-In:
Enabling “Microphone Boost” will increase a volume gain to boost
microphone input signals. If you connect your microphone to the front
panel audio module, enable “Front Panel Microphone”. For typical
low-cost PC microphone, it’s recommended to enable this function.
6
2
4
1 7
3
5
(continued on the next page)
