ASUS Xonar DSX
6.4.2 10-Band Equalizer
The equalizer can modify the audio output for different frequencies, and be used
to compensate for deciencies in your speakers/systems. There are 12 default
patterns and you can also make your own settings.
No Item Description
1 Default equalizer
options
There are 12 available equalizer patterns. Click one to apply it.
2 Equalier slider Adjust the gain for each band (30~16KHz)
3 User Dened You can click this button to apply your own dened parameters saved
in the pull-down menu.
4 Save name Key in a name for your own “User Dened” equalizer setting
5 Add / save Click this “+” button to save the parameters into User Dened list
6 Delete Click this “–” button to delete the parameters from User Dened list
1 2
3 4 5 6
