ASUS Z87-DELUXE/DUAL

2-9

Chapter 2

2.1.7 Front I/O Connector

To install ASUS Q-Connector

USB 2.0

AAFP

To install USB 2.0 connector To install front panel audio connector

USB 3.0

To install USB 3.0 connector

HDD LED

POWER SW

RESET SW

HDD LED-

HDD LED+

PWR

Reset

Ground

HDD LED

Questions and Answers:

Need help?

Do you have a question about the Asus Z87-Deluxe/Dual and is the answer not in the manual?

General

Form Factor	ATX
Socket	LGA 1150
Chipset	Intel Z87
Memory Slots	4
Max Memory	32GB
PCI Express 3.0 x16	2
PCI Express 2.0 x16	1
PCI Express x1	2
SATA 6Gb/s	6
RAID Support	0, 1, 5, 10
Audio	Realtek ALC1150 8-Channel High Definition Audio CODEC
Wireless	Wi-Fi 802.11 a/b/g/n/ac
Memory Standard	DDR3 1600/1333 MHz
USB 3.0	6
LAN	Gigabit Ethernet
Bluetooth	Bluetooth V4.0
