1-6
Chapter 1: Product introduction
1.2.2 Rear panel connectors
Ethernet port
Speed
LED
Activity Link
LED
Activity/Link LED Speed LED
Status Description Status Description
Off Nolink OFF 10Mbpsconnection
Orange Linked ORANGE 100Mbpsconnection
Orange(Blinking) Dataactivity GREEN 1Gbps connection
Orange(Blinking
then steady)
Ready to wake
upfromS5mode
1 2
7 10 11
3 4 5 6
98
1. PS/2 Mouse (green) port.ThisportisforaPS/2mouse.
2. Video Graphics Adapter (VGA) port.This15-pinportisforaVGAmonitororother
VGA-compatibledevices.
3. USB 3.2 Gen 1 (up to 5Gbps) ports.These9-pinUniversalSerialBus(USB)ports
connecttoUSB3.2Gen1devices.
4. Ethernet port.ThisportallowsGigabitconnectiontoaLocalAreaNetwork(LAN)
throughanetworkhub.RefertothetablebelowfortheEthernetportLEDindications.
Ethernet port LED indications
5. Line In port (light blue).Thisportconnectsthetape,CD,DVDplayer,orotheraudio
sources.
6. Line Out port (lime).Thisportconnectsaheadphoneoraspeaker.In4-channel,
5.1-channel,and7.1-channelcongurations,thefunctionofthisportbecomesFront
Speaker Out.
7. PS/2 keyboard (purple) port.ThisportisforaPS/2keyboard.
8. DisplayPorts.TheseportsareforDisplayPort-compatibledevices.
9. HDMI
TM
port.ThisportisforaHigh-DenitionMultimediaInterface(HDMI
TM
)
connector,andisHDCPcompliantallowingplaybackofHDDVD,Blu-ray,andother
protected content.
10. USB 2.0 ports.These4-pinUniversalSerialBus(USB)portsareforUSB2.0devices.
