Asyril Asycube 380 - Backlight

Asycube 380 & 530
Operating Manual
000.101.151
Version: B
24/50
Figure 2-19: Dimension of platform 530
Backlight
The following backlights are available:
Asycube 380 & 530 backlight
Colour
Wavelength
Blue
465 nm
Green
550 nm
Infrared
850 nm
Red
645 nm
White
6500 K
The backlight is supplied fitted when it is ordered at the same time as the Asycube.
