General characteristics
IMPORTANT!
Do not use the device outside the specifications. Failure to follow this instruction will
invalidate the warranty.
Technical features
Asycube 380
Asycube 530
Typical part size
length of side: 15 mm to 60 mm
length of side: 30 mm to 150 mm
Integrated high power
LED backlight
Optional
Optional
Interchangeable
backlight colour
(green, red, blue, white, infra-red), see
additional information in section 2.5.2
(green, red, blue, white, infra-red), see
additional information in section 2.5.2
Independent vibrations
in three orthogonal
directions
Interchangeable
vibration surface
For more information, please refer to
section 2.5.1. Additional platform
For more information, please refer to
section 2.5.1. Additional platform
Configurable vibration
frequency
20 to 30 Hz
20 to 28 Hz
Maximum weight on the
platform (components)
1.5 kg
2 kg
Digital output for
hoppers
2
2
Digital input
2
2
Analogue output
2
2
RoHS
