SPECIFICATIONS
DMP 808
Input Connections Balanced Euroblock
Output Connections Balanced Euroblock
Front Panel Indicators
8 x Input/Peak, 8 x Output/Peak,
1 x Power, 1 x Disable
Signal to Noise (20Hz-20KHz, unweighted) >110dB
Frequency Response 20Hz-20kHz, +/-1dB
Input Impedance 20K Ohm, balanced
Maximum Input Level 20dBu
Total Harmonic Distortion 0�002%
Processor 40-bit oating point
Input A/D Conversion 24-bit
Output D/A Conversion 24-bit
Sample Rates 44.1 kHz, 48 kHz, Network
DIP Switches Network ID, 0 - F
Parametric Equalizers 4-band, adjustable Q, freq. and level
EQ lters All pass, band pass, hi/lo shelf
Compressor Threshold, range, attack, release
Feedback Silencer Fixed/Dynamic
Auto-mixing Input level, output level
Phantom Power +48V DC
Power & Physical
Power Supply
AC 100 – 240V switching power supply,
15A Edison cable
External Power 2-pin euroblock, +24V DC
Dimensions 1 standard 19” rack unit
