Fig. 13a
4
5
Fig. 13b
1) ON-OFF switch. - 2) USB pendrive port for PC
connecon and to use the «WD2 Service tool wash»
program. - 3) USB pendrive port for inserng or
extracng the pre-lled programs. - 4) USB drive for
emergency release. - 5) Hole for emergency release.
d
HAZARD. If the emergency release is used
while a program is running, very hot water
and chemicals may leak. Therefore, there is a
danger of burns, scalding and irritaon.
a
WARNING. The maximum weight that
the open door can withstand is 12 Kg. The
maximum volume available is 0.065 m³ or
65 L. The maximum volume of the basket is
0.025 m³ or 25 L.
