EN 5
YOUR HOB
Ceramic hob
1. Cooking zone Ø 145 / 1200 W
2. Expandable cooking zone Ø 210-120 / 2200-800 W
3. Expandable cooking zone Ø 180-120 / 1700-700 W
4. Cooking zone Ø 145 / 1200 W
5. On/off Indicator hob
6. Residual heat indication by zone
7. Control knob cooking zone left front
8. Control knob cooking zone left back
9. Control knob cooking zone right back
10. Control knob cooking zone right front
1
2
3
765 8 9 10
4
