Product information
VA3.. VA9011XT..ZT..VA..VA(9)6211Q..R..S..T
MPr 28112005
- 9
-
Soap dispenser
Function:
At the first pulse the soap dispenser is opened. Lever A is put in the position which
facilitates – at the next pulses – the operation of lever B (each pulse lasting 20 seconds).
Depending on the chosen amount of
rinsing aid, this lever B is being
activated (2 ml per pulse)
Setting Pulses
0 0
1 2
2 3
3 4
4 5
5 6
6 7
Tank total 120 ml
The soap dispensers in the other models are controlled by means of an actuator. This
actuator is being controlled for two minutes continuously. That is why these dispensers
are not interchangeable!
Sufficient
Top control. Only for ST and TT
Empty
