17
8. Power Supply
◇ NEVER connect the CM-BASEα to power other than DC24V
(allowable fluctuation is ±10%).
◇ NEVER use a power cable that is damaged, cut, broken, or
altered. Fire, electrical shock or burns may occur.
To purchase replacement power cables, contact an Authorized
ATAGO Distributor.
① Make sure that the cable is properly connected to the port.
② Once the power (DC24V) is turned on to the instrument, either the green light or red
light will come on.
m The CM-BASEα has no power switch. When power (DC24V) is supplied to the
CM-BASEα, the measurement value display illuminates and the Brix(%)
measurement commences.
The green light comes on when a sufficient amount of liquid with a Brix value of -2.0 to
33.5% is passing by the prism. When there is not enough liquid passing by, the red light
turns on and error message "LLL" is displayed. When the Brix of the liquid is above
33.6% or more, the red light turns on and "HHH" is displayed.
