7
INSTALLATION
INSTALLATION
Wall Installation
1 Reposition the base wedge for wall use.
Press on the base wedge as shown in figure a to remove the
wedge. Turn the wedge so that the larger end is toward the
bottom of the telephone. Reattach the wedge by positioning it
as shown in figure c and sliding it in the direction of the arrows
until it locks in place.
2 Connect the short telephone line cord to the telephone.
Plug one end of the short line cord into the jack labeled
TEL LINE and thread the cord through the tabs under
the phone as shown.
continued on page 8
figure a figure b
figure c
