Connecting the 8510T to the System
Next, reconnect the cords of the 8510T terminal. See Figure 1 for the
location of the jacks.
1 Plug in the line cord into the Line jack, and plug in the adjunct
equipment cord into the Adjunct jack, if necessary.
2 Turn the terminal right side up, with the front facing you.
3 Decide whether you want the kickstand up, lifted from the desktop
stand, or whether you want the kickstand down, level with the
desktop stand. Check which of these kickstand adjustments allows
you the best viewing angle of the display.
4 Snap the free end of the line cord into the wall jack. Lift the handset
and listen for the dial tone.
Copyright 1993 AT&T
All Rights Reserved
15
