8
.5°C
Set point:
COMFORT
21.5°C
Set point:
Wed. 11:00
CONFIG.
BOOST
MODE
Wednesday
11:00
COMFORT
.5°C
Set point:
.5°C
Set point:
main
switch
open window
self adaptive
error messages
EASY MODE
Low Surface
Temperature
MODE
AWAY status for
geofencing
err03
EASY
LST 75%
The control is based on four buttons and a TFT display.
Switching ON (Master):
Once the radiator has been mounted on the wall
and correctly connected to the main electricity power
supply, press the main On-Off switch on the right
hand side of the radiator.
After around 3 seconds the screen will show various
information and the radiator is ready to operate. It is
recommended to leave the radiator on and use the
standby function (below) to turn the radiator off.
Switching OFF (Master):
To switch off the radiator press the main On-Off
switch on the right hand side of the radiator. The TFT
screen will turn blank and the radiator will lose any
connection with the SunRayRF Gateway.
Stand-by function:
From any on screen press the Mode/OK button
until the symbol is present as shown in the
following screen.
When the radiator is in Stand-by Mode it will retain
programs and continue to communicate with the
SunRayRF Gateway(if connected) but will not heat.
To switch the radiator on again, press the MODE
button to choose programme mode or manual
mode you will see the following screens:
In any of the operation modes the area above
the temperature set point may display a message
showing the status of the Radiator, see the following
screens:
Decrease
Increase Mode/OK
AUTO / MANUAL /OFF
BOOST
CONFIG
(long press)
Current time
Current mode if
AUTO is selected
Set point temperature
Day of the week
Heating indicator
Radio paired icon
Current Mode
(AUTO, MANUAL, OFF)
Sun Ray RF Radiator Controls
OPERATING INSTRUCTIONS
Notication area
The rst press of any button will wake up the radiator any
further button presses will activate the function required.
