While hold input is active, value on the screen is fixed when the signal comes of hold input. If signal of hold
input isn't cut, counting can not to be continued. While you select the hold input, also select the edge you
will make reset on. You can select one of rising and falling edges. If you want to hold off Input, select to off
option. In order to select to hold input pressed to prg button at operating mode and found hold menu with
up-down button. When prg button is pressed, options will flash and made the selection with up-down button.
Then save it by prg button.
Holdtyp menu is selected counting in the background, when value of on the screen is fixed (while hold
input is active). The value of on the screen is fixed, if hold signal is applied while count option is active.
When signal is interrupted, continue to counted value. In order to select hold type, pressed to prg button
at operating mode and found h.type menu with up-down button. When prg button is pressed, options will
flash and made the selection with up-down button. Then saved it by prg button and Returned with rst
button to operatin mode.
The used sensor type can be selected from this menu. The sensor output signal is selectable as NPN or
PNP. In order to selected sensor type, pressed to prg button at operating mode and fount S.typ menu with
up-down button. When prg button is pressed, options will flash and made the selection with up-down button.
Then save it by prg button and returne with rst button to operating mode.
4.11. Activating The Hold Input (Hold)
4.13. Selection Sensor Type (Npn/Pnp) (Senstyp)
4.12. Selection of Hold Type (Holdtyp)
