Atek ALC 77-C User Manual

+
-
+
-
-
L
N
Supply Voltage
24 VAC / DC or
85 / 265 VAC
GND
+5 Vdc or +12 Vdc
A Input of Counting
Signal
girişi
B Input of Counting Signal
Z Input of Reset
Signal
girişi
Input of Hold
Signal
girişi
TX
RX
GND
RS-232
These outputs are optional.
These terminals are open,
if is not specified when
ordering
.
CO
M
NO
NC
CO
M
NO
NC
OUT 2
OUT 1
Ground of Sensor
ucu
Ground
SAFETY WARNINGS
1. Follow the instructions and warnings in the user guide.
2. Please check the type of power supply before connects energy to the device.
3. Please the device mounted on panel against dangers of fall, snap, shake during working.
4. Make Sensor connections without energy on the device; do not connect in any way during
operation.
5. Make sure that is shielded cables between device and sensor.
6. Do not leave the device exposed to a heat source (solar, heater etc.)
7. ALC77 industrial control device is not suitable for use in the external environment, Use only
room conditions.
8. Wipe with a damp cloth to clean the device, do not use water, thinner etc.
9. Comply with the limit values specified in the technical specifications for relay outputs.
10. The device cannot be changed by the user in the event of a fault, Please contact our technical
service in case of failure.
2. CONNECTIONS
- 2 -
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
