Page #11 background imageLoading...
Page #11 background image
QSG_F670_363.00_EN_01_2021-02-09
11/42
Ref
Name
Description
1
J12
Printer RS232 connector / Modbus (option)
2
J1
Analog outputs – test pressure and leak pressure (option)
3
J8
Program selection extension connector (option)
4
J10*
Extender (not operational)
5
J14*
Extender (not operational)
6
J5
Fieldbus connector
7
-
Input connector to the air filter (valves or regulator air supply)
8
-
0.6 MPa valves air supply input (1 MPa range)
9
-
Optional fitting according to special configuration
10
-
Optional fitting according to special configuration
11
-
Vacuum supply input (option)
12
R
Reference output
13
P2
External back pressure connector (option)
14
-
Test part exhaust (also for test pressure sensor auto zero)
15
ATEQ
Air supply energy information
16
-
Part number / Serial number
17
P1
External back pressure connector (option)
18
T
Test output
19
V
Volume for calibration check (option)
20
Y2
T1+T2 tests output (option)
21
B
B automatic connector option
22
Y1
T1+T2 tests output (option)
23
A
A automatic connector option
24
J6
Fieldbus connector
25
J4*
Extender (not operational)
26
J15
Outputs code board connector (digital inputs/outputs) (option)
27
J11*
Extender (not operational)
28
J9
Relay board connector (digital inputs/outputs) (option)
29
J3*
Not operational
30
J2*
Not operational
31
-
Ground
32
J7
Connector for 100 / 240 V AC power supply
33
J13
Connector Profibus (option)
*
These connectors are not operational. They are provided for future development of our
devices
.
