10 stAnD: 2022-01, ProDUKthersteller Ath-heinl Gmbh & co KG

Possibility of saving the job records of the operations

performed on the vehicles (“Customer databank”).

- LCD colour monitor

- Colour INKJET printer.

- Professional alphanumeric keyboard

- Exceptional operating freedom, the user can shift adju-

stments as desired

- Steering measurement in automatic or directly from

targets

- Data can be viewed in sexagesimal, centesimal degrees,

millimetres and inches.

- Graph comparison between data read and the values in

the databank

- Vehicle chassis diagnosis

- Self-centring clamp, 10” to 21”,

• O-centre compensation program (ROC):

• “Push- Mode ROC”

- simultaneous compensation on the four wheels by

pushing the vehicle for a distance corresponding to a

wheel rotation of approximately 30°;

- applicable to 4WD vehicles.

MAIN FEATURES

Program developed on the Windows® platform.

Angle reading with infrared CCD cameras

- 0.01 degree data display

- Databank on Hard disk or CD-ROM

- User databank and jobs archive

On-screen Help available from any point of the program

by pressing the dedicated key.

Option settings (e.g.: mm / inches, °60 / °100, etc.) easily

congured within each program context using menus

recalled by pressing a dedicated key.

Main vehicle databank containing over 19,000 vehicles

with the associated reference data for the angles.

Personalised vehicle databank, containing the vehicles and

data entered by the user using the “insert”, “modify”,

“delete” functions.

Vehicles from the main and customised databank displayed

in a single list for easier consultation.

Handling of reference data for adjustments based on

vehicle chassis height (for vehicles which support this

mode).
