14
Ordering Codes
Alarms Code
B = High alarm only
C = Low alarm only
D = High and low alarm
0 = None
Control Options
Code
0 = Proportional
(Standard)
A = 3-mode (PID)
Athena’s ZC/PC solid state
contactors, and Series 91 and
93 or Series 19 and 39 SCR
power controllers, can be
added to boost ac load
switching capacity.
The deviation meter spans a
range of
+
and reads in
increments of 0.5°.
Sensor Input Code
0 = Thermocouple
2 = RTD
STANDARD RANGE CODE
Thermocouple
Code Set Range Type
14F 100 to +400°F “T”
03F 0 to +300°F “J”
04F 0 to +400°F “J”
13F -100 to +350°F “J”
16F 100 to +600°F “J”
08F 0 to +800°F “J”
01F 0 to +1000°F “J”
03C 0 to +300°C “J”
05C 0 to +500°C “J”
51F 500 to +1500°F “K”
02F 0 to +2000°F “K”
25F 0 to +2500°F “K”
01C 0 to +1000°C “K”
30F 0 to +3000°F “R”
R
TD (3-wire, 100 ohms)
R26 -200 to +600°F
R81 80 to +120°F
R30 0 to +300°F
R60 0 to +600°F
R10 0 to +1000°F
R11 -100 to +100°C
R23 200 to +300°C
R06 0 to +600°C
Special Options
(Consult Factory)
2
0
0
Output type (Plug-In) Code
B = SPDT Relay, 5 A/7 A
F = 4-20 mAdc
T = SPST SS Relay, 1 A
S = Pulsed 20 Vdc
L = Limit Control
Alarms Code
B = High alarm only
C = Low alarm only
D = High and low alarm
Control Options
Code
0 = Proportional
(Standard)
A = 3-mode (PID)
Athena’s ZC/PC solid state
contactors, and Series 91 and
93 or Series 19 and 39 SCR
power controllers, can be
added to boost ac load
switching capacity.
Sensor Input
Code
0 = Thermocouple
2 = RTD
STANDARD RANGE CODE
Thermocouple
Code Set Range Type
01F 0 to +999°F “J”
05C 0 to +500°C “J”
02F 0 to +1999°F “K”
R
TD (3-wire, 100 ohms)
R06 0 to +600°C 100 ohm
R10 0 to +999°F 100 ohm
Special Options
(Consult Factory)
3 2
0
Output type (Plug-In) Code
B = SPDT Relay, 5 A/7 A
F = 4-20 mAdc
T = SPST SS Relay, 1 A
S = Pulsed 20 Vdc
