Page #18 background image
A228/A248/A228I/A248I User’s manual
MECHANICAL SPECIFICATIONS
Architecture
Close-frame
Front Bezel
glass bezel with capacitive touch screen
Color
Medical-white
Mounting / Holder
VESA 100mm
Construction
3mm ABS + PC TYPE Plastic housing
Dimension (WxHxD)
A228/A228i 527 x 330 x 40 mm
A248/A248i 575 x 355 x 40 mm
Net Weight
A228: 5.1kg (w/o power adapter)
A228i: 5.3kg (w/o power adapter)
A248: 6.9 kg (w/o power adapter)
A248i: 7.4kg (w/o power adapter)
Packing Filler
PE
CONFIGURATION 2 - P.CAP TOUCH
Type
Full flat projective capacitive 10p touch panel
Interface
Controller with USB interface, 5V
Resolution
100ppi to 25ppi Based WIN7 definition ppi
(Pixel per inch)
Light Transmission
90% ± 3%
Life Time
100M times
