APPENDIX
28
A228/A248/A228I/A248I User’s manual
APPENDIX A
A. CONNECTORS
This appendix gives the of connectors.
Ethernet Port
Pin #
Signal Description
1
Data0+
2
Data0-
3
Data1+
4
Data2+
5
Data2-
6
Data1-
7
Data3+
8
Data3-
